Sliding Series – S70mm Sliding & S75mm Sliding Cedar
Sliding Series – S70mm Sliding & S75mm Sliding
The Selenit Series, designed at the highest level of aesthetics, performance and durability standards, offers a new window for modern structures. The series was developed for those who were looking for a solution that captures the zeitgeist under the changing life culture and living space concepts. The Selenit Series offers a complete system with its 70/75 millimeter profile width, 6-cell design and 3rd gasket option, which enable it to achieve the highest levels of performance.
Guaranteed Safe Checkout
GENERAL INFORMATION
*{
font-family: roboto !important;
}
- Main Profile & Efficiency
- Wind Load Resistance
- DIAMOND 60 systems successfully passed the safety test of 2.000 Pa (1655 km/h) wind load resistance.
| Frame & Sash
Profile Width - mm |
Number of Seal | Kind of Seal | Number of outside
Chambers |
Sound Insulati on – DB Decibels | Air
Permeabi lity class |
Water imperme
ability class |
Profile heat insulation | Wind load resistance | Glass
Thickness |
| 60 | 2 | TPE | 4 | 38 | 4 | 9A | 1.63
W/m2 ºK |
C3 | 5, 20, 24,
32 |
- Under tests carried out with 600 Pa (110 km/h) wind load and 4 liters of rainwater per minute, the system did not leak any water inside and proved its high quality.
- Heat insulation
- By means of the chamber numbers, chamber widths and profile heights developed in consideration of the profile width, DIAMOND 60 system is able to meet all requirements regarding the thermal conductivity coefficient.
- In accordance with the TS EN ISO 10077-2 standard, the window system with the dimensions of 1,23 m x 1,43 m has achieved the values of Uw:1,46 W/m2 ºK and Uf:1,63 W/m2 ºK.
- Sound insulation
- DIAMOND 60 Series provides sound insulation with values up to 38 dB. Therefore, it is possible to create a sound environment at a high quality life level even at the loudest places.
- The sound insulation level to be acquired via acoustic glasses that can be used with the system, isolates the outside noise of outdoors from indoors in the most efficient way.
MAIN PROFILES
- Main Profile & Efficiency
- Wind Load Resistance
- DIAMOND 60 systems successfully passed the safety test of 2.000 Pa (1655 km/h) wind load resistance.
- Wind Load Resistance
| Profile Width | Number of Chambers | Profile Heat Insulation | Window Heat Insulation | Sound Insulation |
|---|---|---|---|---|
| 60 mm | 4 | 1,46 W/m2 ºK | 1,63 W/m2 ºK | 38 db |
| Air Permeability Class | Water Impermeability Class | Wind Load Resistance Class | Glass Thickness (mm) |
|---|---|---|---|
| 4 | 9A | C3 | 5, 20, 24, 32 |
- Under tests carried out with 600 Pa (110 km/h) wind load and 4 liters of rainwater per minute, the system did not leak any water inside and proved its high quality.
- Heat insulation
- By means of the chamber numbers, chamber widths and profile heights developed in consideration of the profile width, DIAMOND 60 system is able to meet all requirements regarding the thermal conductivity coefficient.
- In accordance with the TS EN ISO 10077-2 standard, the window system with the dimensions of 1,23 m x 1,43 m has achieved the values of Uw:1,46 W/m2 ºK and Uf:1,63 W/m2 ºK.
- Sound insulation
- DIAMOND 60 Series provides sound insulation with values up to 38 dB. Therefore, it is possible to create a sound environment at a high quality life level even at the loudest places.
- The sound insulation level to be acquired via acoustic glasses that can be used with the system, isolates the outside noise of outdoors from indoors in the most efficient way.
- Heat insulation
